The Topcon 1051612-22-K2-LS-B200W-MM is a purpose-built excavation package that puts real-time cut/fill grade information directly in front of your machine operator — without the cost of a full 3D GPS system. Pairing the field-proven RL-HV2S dual grade rotating laser with the LS-B200W wireless machine-mounted receiver and the LS-100D handheld rod receiver, this kit covers both cab-based grading and traditional grade rod work on the same job. Whether you're cutting utilities, benching pads, or maintaining slope on a drainage channel, this system delivers the accuracy and flexibility that working contractors depend on.
System Overview & Jobsite Applications
At the core of this package is the RL-HV2S, a self-leveling dual-grade laser capable of projecting a precisely inclined plane in both the X and Y axes simultaneously — ideal for crowned roads, sloped pads, and complex grading profiles. The LS-B200W receiver mounts directly to the boom or blade of an excavator or dozer, transmitting grade data wirelessly to an in-cab digital display. Operators get instant visual feedback on cut and fill without stopping to check grade manually, tightening cycle times and reducing over-excavation. The included LS-100D handheld receiver keeps your rod crew productive alongside the machine, confirming elevations, setting offsets, and checking finished grade without interrupting machine operation.
Key Specifications
- Laser Model: Topcon RL-HV2S Self-Leveling Dual Grade Rotating Laser
- Grade Range: ±10% on both axes simultaneously
- Leveling Accuracy: ±10 arc seconds automatic self-leveling
- Operating Range: Up to 800m diameter (single receiver)
- Machine Receiver: LS-B200W Wireless Machine-Mounted Receiver
- Wireless Transmission: Integrated wireless link between LS-B200W and in-cab display (no cable runs on machine)
- Handheld Receiver: LS-100D with digital numeric readout and audible grade indication
- Mounting: Magnetic mount included for tool-free setup on steel machine components
- IP Rating: Dust and water resistant construction on all components
- Power: Rechargeable battery system; runtime suitable for full shift operation
What's in the Kit
- Topcon RL-HV2S Dual Grade Self-Leveling Rotating Laser
- LS-B200W Wireless Machine-Mounted Grade Receiver
- In-cab digital display unit for LS-B200W
- LS-100D Handheld Rod Receiver
- Magnetic mount for machine receiver attachment
- Rechargeable battery packs and chargers
- Carrying case for transport and storage
- Operator manual and quick-start documentation
Job Applications
Utility Trench Excavation: Mount the LS-B200W to the excavator boom and dial in your design slope on the RL-HV2S. The operator reads grade continuously in the cab, keeping invert elevation consistent through the full run without repeated manual checks.
Building Pad Preparation: Use the dual-grade capability to set a two-direction fall on a commercial slab or parking lot subgrade. The handheld LS-100D lets your grade checker verify corners and edges independently while the machine works the field.
Road Subgrade & Crowned Surfaces: Program cross-slope and longitudinal grade simultaneously on the RL-HV2S. Dozer operators maintain consistent crown profile across the full width of the road without stopping to pull a string line.
Drainage Channel & Swale Grading: Set a consistent channel fall rate and let the excavator operator track grade in real time. Reduces over-digging and limits material haul-off on tight-margin earthwork contracts.
Compatible Accessories
Frequently Asked Questions
- Does the LS-B200W require a cable connection to the in-cab display?
- No. The LS-B200W uses an integrated wireless link to transmit grade data to the in-cab display unit, eliminating cables across pivot points and machine joints. This significantly reduces setup time and wear-related maintenance on the receiver system.
- Can this package handle two different slopes at the same time?
- Yes. The RL-HV2S is a dual-grade laser, meaning it can be set to independent X-axis and Y-axis grades simultaneously. This is particularly useful for crowned road subgrades, sloped pads with directional drainage, and any surface requiring a compound fall.
- Is the LS-100D handheld receiver usable at the same time as the machine receiver?
- Yes. The LS-100D operates independently on the same laser plane as the LS-B200W, so your grade checker can work alongside the machine without any interference or system switching. Both receivers read from the same rotating laser simultaneously.
- What is the effective working range of this system on a large site?
- The RL-HV2S has an operating diameter of up to 800 meters with a single receiver under normal conditions. For most excavation and grading applications, a single instrument setup will cover the full working area of one machine through an entire shift without repositioning.
