The Leica Piper 200G (Model 6016959) sets the performance standard for pipe lasers in sewer and underground utility construction. Combining a high-visibility green beam, integrated laser plumb reference, and the precision AlignMaster target system, the Piper 200G delivers grade control accuracy that satisfies the tightest municipal and DOT specifications. Whether you're laying gravity sewer mains, storm drainage pipe, or underground conduit systems, this instrument gives your crew reliable, repeatable elevation control shift after shift.
Product Overview
Engineered for demanding jobsite conditions, the Leica Piper 200G operates across grades from -10% to +15% and is rated IP67 for full dust and water resistance. The instrument self-levels within its compensator range and alerts the operator immediately when that range is exceeded — eliminating costly relays errors. Its green laser diode produces a beam up to five times more visible than comparable red beam systems, making target acquisition faster and reducing crew fatigue during long production days in confined or low-light environments.
Key Specifications
- Model Number: 6016959
- Beam Color: Green (520 nm)
- Grade Range: -10% to +15%
- Accuracy: ±1.5 mm at 10 m
- Self-Leveling Range: ±5°
- Plumb Reference: Integrated laser plumb dot
- Working Range: Up to 200 m (660 ft)
- Battery Life: Up to 100 hours (alkaline)
- Protection Rating: IP67 (dust-tight, 1 m submersion)
- Operating Temperature: -20°C to +50°C (-4°F to 122°F)
- Weight: Approx. 3.5 kg (7.7 lb) with batteries
Key Features
- AlignMaster Target: Dedicated alignment target with digital readout for precise horizontal and vertical positioning inside the pipe
- Green Beam Visibility: Significantly enhanced beam detection vs. red diode systems — critical in large-diameter or long-run pipes
- Integrated Plumb Reference: Built-in laser plumb dot for fast, accurate instrument centering over invert without additional tools
- Automatic Self-Leveling: Compensator levels the beam automatically and triggers an audible/visual out-of-level warning
- Wide Grade Range: Handles steep grades without manual tilt head accessories on most production applications
- IP67 Waterproof Construction: Survives pipe trench conditions, rain, and incidental submersion
- Long Battery Runtime: Up to 100-hour operation on standard alkaline D-cells — reduced battery changes on long projects
- Remote Control Compatible: Supports optional wireless remote for grade and alignment adjustments without entering the pipe
Job Applications
Municipal Gravity Sewer Installation: Maintain consistent invert elevations across hundreds of feet of sewer main. The AlignMaster target gives the pipe crew a clear, quantified offset reading for both grade and horizontal alignment simultaneously.
Stormwater & Drainage Infrastructure: Precise grade control on storm drain installations prevents low spots and standing water issues that generate expensive warranty callbacks. The Piper 200G holds grade reliably from manhole to manhole.
Directional Bore & Casing Work: The integrated plumb reference and long working range make the Piper 200G a natural fit for casing installations where the bore pit limits repositioning options.
Underground Conduit & Utility Duct Banks: Telecom, electrical, and gas contractors use pipe lasers to maintain minimum required cover and consistent grade for drainage compliance on duct bank installations.
Compatible Accessories
- Leica AlignMaster Target for Piper 200G
- Leica Piper Remote Control Unit
- Leica Pipe Laser Tripod & Centering Rod Kit
- Leica Piper Carrying Case & Transport Bag
- Replacement Alkaline Battery Pack (D-Cell)
Related Guides
- How to Set Up a Pipe Laser for Gravity Sewer Installation
- Green Beam vs. Red Beam Pipe Lasers: Which Should You Choose?
- Pipe Laser Accuracy Standards for Municipal Sewer Projects
- Leica Piper 200G vs. Piper 100G: Feature Comparison
Frequently Asked Questions
- What is the working range of the Leica Piper 200G?
- The Piper 200G has a maximum working range of approximately 200 meters (660 feet), making it suitable for long sewer main runs between manholes without repositioning the instrument.
- Does the Piper 200G include the AlignMaster target?
- Availability of included accessories can vary by kit configuration. Contact Express Tools to confirm exactly what is included with your specific order, or ask about bundling the AlignMaster target with your purchase.
- How does the green beam improve productivity over a red beam pipe laser?
- The green laser diode (520 nm) is perceived by the human eye as significantly brighter than a red diode at equivalent power output. In large-diameter pipes, ambient light conditions, or dusty environments, crews acquire and read the target faster — reducing setup time and minimizing re-checks.
- Is the Leica Piper 200G compatible with a wireless remote control?
- Yes. The Piper 200G supports an optional Leica remote control unit that allows the operator to adjust grade settings and alignment from outside the pipe, eliminating the need to re-enter the pipe for minor corrections during production.
Frequently Asked Questions
What is the working range of the Leica Piper 200G?
The Piper 200G has a maximum working range of approximately 200 meters (660 feet), making it suitable for long sewer main runs between manholes without repositioning the instrument.
Does the Piper 200G include the AlignMaster target?
Availability of included accessories can vary by kit configuration. Contact Express Tools to confirm exactly what is included with your specific order, or ask about bundling the AlignMaster target with your purchase.
How does the green beam improve productivity over a red beam pipe laser?
The green laser diode (520 nm) is perceived by the human eye as significantly brighter than a red diode at equivalent power output. In large-diameter pipes, ambient light conditions, or dusty environments, crews acquire and read the target faster — reducing setup time and minimizing re-checks.
Is the Leica Piper 200G compatible with a wireless remote control?
Yes. The Piper 200G supports an optional Leica remote control unit that allows the operator to adjust grade settings and alignment from outside the pipe, eliminating the need to re-enter the pipe for minor corrections during production.
