Topcon RL-H5A Self-Leveling Laser Kit

Description

```html

Overview

The Topcon RL-H5A Self-Leveling Rotary Laser is a professional-grade leveling solution designed for general contractors, excavators, concrete professionals, and site preparation crews who demand reliable horizontal accuracy across large work areas. This complete kit configuration pairs the field-proven RL-H5A laser head with the LS-100D deluxe receiver—one of the most sensitive detectors in its class—plus a rechargeable battery system, grade rod marked in tenths, and heavy-duty tripod. It's a turnkey package that eliminates guesswork on compatibility and gets crews operational immediately. Whether you're setting forms, grading building pads, installing drop ceilings, or establishing drainage slopes, this kit delivers consistent ±1/16" accuracy at 100 feet with working diameter exceeding 1,600 feet under optimal conditions.

Key Specifications

Self-Leveling Range: ±5 degrees (manual slope capability in single axis)
Leveling Accuracy: ±1/16 inch at 100 feet (±1.6 mm at 30 m)
Working Diameter: 1,600+ feet (500+ meters) with LS-100D receiver
Rotation Speed: 600 RPM (variable speed optional on some modes)
Environmental Rating: IP66 dust-tight and water-resistant
Power System: Rechargeable Ni-MH battery pack (included); alkaline D-cell compatible
Battery Life: 100+ hours on single charge (standard rotation mode)
Operating Temperature: -4°F to 122°F (-20°C to 50°C)
Laser Unit Weight: 5.3 lbs (2.4 kg) with battery

What's in the Kit

RL-H5A Laser Head: Self-leveling rotary unit with horizontal and manual-grade modes
LS-100D Laser Receiver: Deluxe rod-mounted detector with multi-zone LCD, audio alerts, and fine/standard detection modes for maximum versatility
Rechargeable Battery Pack: Ni-MH system with AC charger for cost-effective operation
Alkaline Battery Tray: Backup power option using standard D-cell batteries
Grade Rod (Tenths): Telescoping measuring rod graduated in 0.1-foot increments for direct elevation readings
Heavy-Duty Tripod: Adjustable-height aluminum tripod with quick-release laser mount and stabilizing feet
Hard-Shell Carrying Case: Impact-resistant storage case with custom foam inserts for laser, receiver, and accessories
Remote Control: RC-200 infrared remote for rotation speed and scan mode adjustments from up to 100 feet
Target Plate: Reflective laser target for indoor and close-range layout work
User Documentation: Quick-start guide and full operation manual

Job Applications

Foundation and Footing Layout: Verify excavation depth and establish consistent form heights across multi-pier foundations where even small elevation errors compound structural issues.
Site Grading and Drainage: Set grade stakes for parking lots, building pads, and drainage swales—the RL-H5A's manual slope function creates precise gradients for positive water flow.
Concrete Flatwork: Establish screed rails and check slab elevation during pours to maintain specified thickness and avoid costly material overruns or low spots.
Drop Ceiling Installation: Quickly level grid systems in commercial spaces by rotating a continuous reference plane around entire rooms, eliminating string lines and tedious transfer measurements.
Underground Utility Trenching: Monitor trench depth and slope during excavation to meet code requirements for sewer, water, and drainage lines without constant grade checks.
Retaining Wall Construction: Ensure courses remain level over long runs and verify backfill grades during step-by-step construction on sloped terrain.

Compatible Accessories

Expand your RL-H5A system with these factory-compatible components:

LS-80L Basic Receiver — economical backup detector for crews running multiple setups
RC-200 Remote Control — replacement or additional remote for multi-crew operations
Aluminum Grade Rod with Tenths — extra rods for simultaneous multi-point checks
Heavy-Duty Flat-Head Tripod — additional tripod for dedicated instrument or quick setup changes
Topcon Ni-MH Rechargeable Battery — spare battery for extended runtime on large projects
Universal Detector Clamp — secure LS-100D to stakes, pipes, or forms when rod mounting isn't practical

Related Guides

How to Set Up and Calibrate a Rotary Laser Level — step-by-step setup procedures and accuracy verification
Topcon RL-H5A vs. Spectra LL500 Comparison — feature and performance analysis of competing horizontal lasers
Understanding Laser Receiver Detection Range — factors affecting working distance and how to maximize reliability
Troubleshooting: Rotary Laser Won't Self-Level — common causes and field solutions for leveling failures
