Can the GL422N handle compound slopes for parking lot crown-to-curb applications?

Yes, the GL422N's independent X and Y axis slope adjustment makes it ideal for compound grades. You can simultaneously set cross-slope for drainage (typically 2%) and longitudinal slope for runoff direction. The RC402N remote allows you to adjust both axes from the work area without returning to the laser, and the grade settings are displayed on the control panel.

What's the practical working range difference between the HL760 and aftermarket receivers?

The HL760 Laserometer provides approximately 800-foot radius range with digital elevation display accurate to 0.01 feet—ideal for finish grading and concrete work. Aftermarket machine receivers like the HR320 extend range to 1,600 feet diameter and offer analog outputs for grade control systems on dozers and excavators, but lack the digital readout.

How does the grade matching feature work when the laser gets bumped during a pour?

The GL422N stores grade settings in memory, so if the laser is knocked out of level, it will automatically return to the previously set grade once repositioned within leveling range. For minor disturbances within the self-leveling capacity, the compensator maintains the grade plane without intervention.

Is annual calibration required, and can I verify accuracy in the field?

Spectra recommends annual calibration to maintain the ±1/16-inch specification. For field verification, perform a two-point accuracy check by setting the laser at midpoint between two grade rods 200 feet apart, recording readings, then moving the laser to one end and comparing results—deviation beyond 1/8 inch total indicates calibration is needed.

Spectra Precision GL422N Dual Grade Laser

Description

```html

Overview

The Spectra Precision GL422N represents the industry standard for dual-grade laser systems, combining horizontal leveling and dual-axis slope capability in a single rotating laser package. Built for contractors who demand accuracy across varied site conditions, this laser delivers ±1/16" at 100 feet precision with motor-driven slope adjustment on both the X and Y axes. The included HL760 Laserometer provides digital readout with 0.01-foot resolution, enabling precise elevation control without constant manual checking. Operating range extends to 1,600 feet diameter with a detector, making it suitable for large commercial sites, grading operations, and concrete pours where maintaining exact grade over distance is critical. The GL422N's fully sealed IP67 housing withstands dust, rain, and jobsite impacts, while the self-leveling mechanism with automatic grade matching reduces setup time on uneven ground.

Key Specifications

Leveling Accuracy: ±1/16 inch at 100 feet (±8 arc seconds)
Working Range: 1,600 feet diameter with HR320 receiver; 800 feet radius with HL760
Slope Range: -9% to +9% on X and Y axes independently
Self-Leveling Range: ±5 degrees with automatic compensation
Rotation Speed: 600 RPM (variable speed available)
Beam Type: Single red diode laser, 635nm wavelength
Power Source: Rechargeable NiMH battery or alkaline D-cells; 40+ hour runtime
Environmental Rating: IP67 dust-tight and waterproof protection
Operating Temperature: -4°F to 122°F (-20°C to 50°C)
Grade Matching: Manual or automatic grade entry with remote control capability
Dimensions: 9.4" x 9.4" x 7.9" (240mm x 240mm x 201mm)
Weight: 13.2 lbs (6 kg) with battery

What's in the Kit

GL422N Dual Grade Laser with rechargeable battery
HL760 Digital Laserometer Receiver with rod clamp
RC402N Remote Control for grade adjustment
Heavy-duty aluminum carrying case with custom foam
110V AC battery charger with international adapters
Laser glasses for beam visibility in bright conditions
Instruction manual and quick-start guide
Calibration certificate and registration card

Job Applications

Site Grading and Excavation: Dual-slope capability allows precise control of drainage planes and complex surface contours without repositioning the laser. Set cross-slopes for parking lots or crown-to-curb grades with independent X/Y axis adjustment, reducing staking requirements and grade checking time.
Concrete Slab Pours: Horizontal mode provides consistent elevation reference across large deck areas up to 1,600 feet diameter. The HL760's digital display eliminates reading errors during screed operations, while automatic grade matching maintains accuracy even when the laser is bumped or moved during multi-day pours.
Utility Trenching: Set precise fall for sewer, storm drain, and water lines using slope mode with 0.01% resolution. The extended working range covers entire trench runs, while the IP67 rating protects electronics from trench water and backfill dust that destroys lesser lasers.
Foundation Layout: Establish benchmark elevations and transfer heights between form locations with 1/16-inch accuracy. The self-leveling mechanism compensates for soft ground settlement during extended setups, maintaining reference plane integrity throughout the forming and inspection process.
Pier and Column Construction: Horizontal reference plane enables consistent elevation control for multi-level structures. Use with multiple receivers simultaneously to monitor several pours or form elevations at once, reducing crew size and improving productivity on vertical construction sequences.
Agricultural Land Leveling: Motor-driven slope adjustment creates uniform drainage grades for field preparation and irrigation systems. The 1,600-foot working diameter covers large agricultural plots from a single setup, while the rugged construction survives the dust and vibration of land-forming equipment.

Compatible Accessories

Frequently Asked Questions

Can the GL422N handle compound slopes for parking lot crown-to-curb applications?: Yes, the GL422N's independent X and Y axis slope adjustment makes it ideal for compound grades. You can simultaneously set cross-slope for drainage (typically 2%) and longitudinal slope for runoff direction. The RC402N remote allows you to adjust both axes from the work area without returning to the laser, and the grade settings are displayed on the control panel. This eliminates the need for multiple setups or string lines when establishing complex drainage planes on parking areas, plaza decks, or athletic fields.
What's the practical working range difference between the HL760 and aftermarket receivers?: The HL760 Laserometer included in this kit provides approximately 800-foot radius range with digital elevation display accurate to 0.01 feet—ideal for finish grading and concrete work where precise readings matter. Aftermarket machine receivers like the HR320 extend range to 1,600 feet diameter and offer analog outputs for grade control systems on dozers and excavators, but lack the digital readout. For most contractors, the HL760 handles form-setting and hand grading while an optional HR320 adds capability for machine-controlled earthwork on the same laser.
How does the grade matching feature work when the laser gets bumped during a pour?: The GL422N stores grade settings in memory, so if the laser is knocked out of level (beyond the 5-degree self-leveling range), it will automatically return to the previously set grade once repositioned within leveling range. For minor disturbances within the self-leveling capacity, the compensator maintains the grade plane without intervention. This is critical during concrete pours or active site work where equipment traffic may cause vibration or minor impacts. The alternative—manual grade re-entry after each disturbance—costs significant time and introduces potential for input errors on time-sensitive pours.
Is annual calibration required, and can I verify accuracy in the field?: Spectra recommends annual calibration to maintain the ±1/16-inch specification, particularly for contractors bidding work with strict tolerance requirements. Most rental houses and equipment dealers offer calibration services with certified test results. For field verification, you can perform a two-point accuracy check by setting the laser at midpoint between two grade rods 200 feet apart, recording readings, then moving the laser to one end and comparing results—deviation beyond 1/8 inch total indicates calibration is needed. This simple test takes 15 minutes and can be performed monthly to catch accuracy drift before it affects work quality or triggers inspection failures.

```
