The Spectra Precision 105516 Vertical Adapter is a precision-engineered mounting accessory that enables contractors and surveyors to instantly convert their HL-series laser receivers from horizontal rod-mounted use to vertical-plane laser applications — no re-calibration, no extra hardware, and no wasted time on the job site. Designed for professionals who demand flexibility from their equipment, the 105516 is a smart addition to any laser leveling kit.
Product Overview
Whether you're plumbing walls, aligning columns, setting grade on vertical structures, or transferring reference points from floor to ceiling, the 105516 vertical adapter eliminates the need to carry separate receivers for each application. Simply attach the adapter to your HL700, HL750, HL750U, or HL760 receiver and reorient your detection axis without breaking down your setup. The adapter accepts both standard tripod thread sizes, making it universally compatible with the mounting hardware already on your truck.
Key Specifications
- Compatible Receivers: HL700, HL750, HL750U, HL760
- Thread Mounts: 5/8-11 and 1/4-20 integrated threaded inserts
- Mounting Style: Tool-free, quick-release attachment
- Application Axis: Converts horizontal receiver orientation to vertical-plane detection
- Build: Rugged construction for jobsite durability
- Part Number: 105516
- Manufacturer: Spectra Precision (Trimble)
Key Features
- Dual Thread Compatibility: Integrated 5/8-11 and 1/4-20 threaded mounts fit virtually all standard survey tripods and grade rods without adapters
- No Re-Setup Required: Transitions receiver from horizontal to vertical applications in seconds, preserving your existing calibration
- Tool-Free Attachment: Fast, secure mounting lets crews stay productive and move quickly between tasks
- Broad Receiver Compatibility: Works across the full HL700 and HL750 series, protecting your investment as your receiver inventory grows
- Compact and Lightweight: Adds minimal bulk to your kit — easy to store in a receiver case or tool bag
- Jobsite-Tough Construction: Built to withstand the vibration, dust, and handling demands of active construction environments
Job Site Applications
The 105516 vertical adapter delivers reliable performance across a wide range of professional applications:
- Wall Plumbing: Mount your HL-series receiver vertically to detect a rotating or plumb laser beam and ensure walls are perfectly plumb during framing and masonry work
- Column Alignment: Quickly verify vertical alignment of structural columns and posts without switching instruments or reconfiguring your laser setup
- Ceiling and Floor Transfers: Transfer reference elevations and layout points from floor to ceiling or overhead structures with precision vertical detection
- Façade and Curtain Wall Layout: Maintain consistent vertical reference lines across large building facades for cladding, curtain wall panels, and exterior finish work
Compatible Accessories
- Spectra Precision HL760 Laser Receiver
- Spectra Precision HL750U Laser Receiver
- Spectra Precision HL750 Laser Receiver
- Spectra Precision HL700 Laser Receiver
- Grade Rod Clamp for HL-Series Receivers
- Spectra Precision Tripod — 5/8-11 Thread
Related Guides
- How to Use a Laser Receiver for Vertical Applications
- Spectra Precision HL-Series Receiver Comparison Guide
- Choosing the Right Laser Level Accessories for Your Job
- Horizontal vs. Vertical Laser Detection: When to Use Each
Frequently Asked Questions
- Which receivers is the Spectra Precision 105516 compatible with?
- The 105516 vertical adapter is designed for use with the Spectra Precision HL700, HL750, HL750U, and HL760 laser receivers. It is not confirmed compatible with receivers outside this series — consult Express Tools if you need to verify compatibility with another model.
- Do I need any tools to attach the 105516 vertical adapter?
- No. The 105516 features a tool-free mounting design that allows you to attach or remove the adapter quickly without any wrenches or hardware. This is especially useful when switching between horizontal and vertical tasks throughout the work day.
- What thread sizes does the 105516 support?
- The adapter includes integrated 5/8-11 and 1/4-20 threaded mounts, covering the two most common thread standards used on surveying tripods and grade rods on North American job sites.
- Will using the vertical adapter affect my receiver's calibration?
- No. The 105516 is a passive mechanical adapter — it physically reorients the receiver without interfering with its internal electronics or calibration settings. Your receiver will perform exactly as it was calibrated once the adapter is attached.
Frequently Asked Questions
Which receivers is the Spectra Precision 105516 compatible with?
The 105516 vertical adapter is designed for use with the Spectra Precision HL700, HL750, HL750U, and HL760 laser receivers. It is not confirmed compatible with receivers outside this series — consult Express Tools if you need to verify compatibility with another model.
Do I need any tools to attach the 105516 vertical adapter?
No. The 105516 features a tool-free mounting design that allows you to attach or remove the adapter quickly without any wrenches or hardware. This is especially useful when switching between horizontal and vertical tasks throughout the work day.
What thread sizes does the 105516 support?
The adapter includes integrated 5/8-11 and 1/4-20 threaded mounts, covering the two most common thread standards used on surveying tripods and grade rods on North American job sites.
Will using the vertical adapter affect my receiver's calibration?
No. The 105516 is a passive mechanical adapter — it physically reorients the receiver without interfering with its internal electronics or calibration settings. Your receiver will perform exactly as it was calibrated once the adapter is attached.
