Overview
The Spectra DG613 Dialgrade Pipe Laser is a professional-grade underground construction tool engineered for municipal utility crews and contractors installing sanitary sewers, storm drains, water lines, and other underground pipe systems. This fully waterproof laser system combines precision grade control with an intuitive dialgrade graphic display that visualizes slope and grade adjustments in real time. Housed in a rugged, compact design built to withstand harsh underground jobsite conditions, the DG613 delivers reliable laser reference lines for accurate pipe placement at depths up to 1,000 feet. The complete kit includes an 8-inch trivet mounting plate for secure setup, remote control for convenient adjustments without entering the trench, and rechargeable battery system for extended operation in remote locations without power access.
Key Specifications
- Laser Type: Visible red diode laser, 635nm wavelength
- Grade Range: -10% to +40% in 0.01% increments
- Accuracy: ±1/16 inch at 100 feet (±1.5mm at 30m)
- Working Range: Up to 1,000 feet (305m) with detector
- Display: Dialgrade graphic LCD with backlight
- Power: Rechargeable NiMH battery pack; up to 40 hours runtime
- Waterproof Rating: IP68 – fully submersible to 16 feet (5m)
- Operating Temperature: 14°F to 122°F (-10°C to 50°C)
- Laser Diameter: 2 inches at 100 feet
- Self-Leveling Range: ±5 degrees
- Mounting: 8-inch trivet plate included
- Dimensions: 9.5 x 7.5 x 7.5 inches
- Weight: 8.8 lbs with battery
What's in the Kit
- Spectra DG613 Dialgrade Pipe Laser
- 8-inch Trivet Mounting Plate
- RC603 Remote Control with Magnetic Mount
- Laser Target with Rod Clamp
- Rechargeable NiMH Battery Pack
- Battery Charger with AC Adapter
- Hard-Shell Carrying Case
- Operator's Manual
- Calibration Certificate
Job Applications
- Sanitary Sewer Installation: The DG613's precise grade control ensures proper flow rates and prevents settling issues in gravity-fed sewer lines. The dialgrade display allows crews to match existing grades and make micro-adjustments for optimal drainage without calculation errors.
- Storm Drain Systems: Maintains consistent slope across long runs of storm pipe, critical for preventing standing water and sediment accumulation. The 1,000-foot range covers extended pipe runs without repositioning, reducing setup time on large commercial and municipal projects.
- Water Line Trenching: Provides accurate depth and grade reference for water main installation, ensuring proper pitch for air release valves and drainage during maintenance. The waterproof design performs reliably in wet trench conditions common during water line work.
- Culvert and Drainage Pipe: The wide grade range (-10% to +40%) accommodates steep slopes required for culverts under roadways and embankments. Remote control functionality allows single-operator grade changes from the pipe end without climbing in and out of deep trenches.
- Horizontal Directional Drilling (HDD): Serves as a reference line for pilot hole drilling and reaming operations, helping crews maintain design grade and avoid obstacles. The compact size fits in tight bore pits where larger laser systems won't work.
- Utility Tunneling: The bright visible red laser remains clearly visible in dark tunnel environments, and the submersible rating protects against groundwater infiltration during below-water-table excavations. Battery operation eliminates the need for power cords in confined spaces.
Compatible Accessories
- Spectra CR700 Laser Receiver with Rod Clamp – extends range in bright conditions
- Replacement 8-inch Aluminum Trivet Plate – spare mounting base
- Spectra RC603 Replacement Remote Control – backup remote
- Professional Laser Target Set with Multiple Sizes – various diameter targets
- Spectra Rechargeable NiMH Battery Pack – spare batteries
- Telescoping Grade Rod with Target Holder – for grade checking
- Laser Detector Cards 10-Pack – manual detection aid
- Heavy-Duty Transport Case for Pipe Lasers – enhanced protection
