Leica DISTO X6 Laser Distance Meter — Bluetooth 5.0, IP65, 820 Ft Range

The Leica DISTO X6 (model 950909) is a professional-grade laser distance meter engineered for contractors, estimators, and field crews who demand more than basic point-to-point readings. With an 820-foot range, IP65 dust and water resistance, and Leica's exclusive Point-to-Point (P2P) technology, the X6 is built to survive and perform on real jobsites — from renovation surveys and existing-conditions documentation to MEP coordination and pre-construction verification.

Overview & Jobsite Applications

The DISTO X6 goes beyond what a tape measure or entry-level laser can do. Its tilt sensor and inclinometer enable indirect measurements to points you can't physically reach, while the Smart Room function captures full room dimensions — length, width, and height — in a single workflow. Bluetooth 5.0 transmits measurements wirelessly to the free Leica DISTO Plan app, compatible with iOS and Android, so data flows directly into sketches, floor plans, or job documentation without a paper middleman. Whether you're estimating flooring on a multifamily renovation, verifying column spacing before a steel order, or documenting existing conditions for a permit set, the X6 reduces re-measure trips and transcription errors.

Key Specifications

• Measuring Range: 0.05 m to 250 m (0.16 ft to 820 ft)
• Accuracy: ±1.0 mm (±1/16 in) typical
['
• IP Rating: IP65 — dust-tight and water-jet resistant
• Bluetooth: Version 5.0 with End-to-End connectivity
• Tilt Sensor Range: ±90° with ±0.1° accuracy
• Display: Color display, reads clearly in direct sunlight
• Battery: 2x AAA alkaline — up to 5,000 measurements per charge
• Dimensions: 140 x 53 x 31 mm / 5.5 x 2.1 x 1.2 in
• Weight: 175 g (6.2 oz) with batteries
• Operating Temperature: -10°C to +50°C (14°F to 122°F)

Key Features

• Point-to-Point (P2P) Technology: Measure between any two points in space — without repositioning the device — using tilt sensor data and dual-laser targeting
• Smart Room Function: Capture all three room dimensions and area/volume in one automated sequence
• Bluetooth 5.0 End-to-End: Transfers measurements directly to the DISTO Plan app, Sketch, or compatible CAD workflows
• IP65 Protection: Sealed against dust and direct water jets — built for active construction environments
• Color Sunlight-Readable Display: High contrast readout visible in bright outdoor conditions
• Multi-Function Measurements: Area, volume, Pythagorean, min/max, stake-out, and indirect height calculations built in
• Memory Storage: Last 30 measurements stored on-device for reference
• Integrated Endpiece: Folds out for corner measurements without an assistant

Job Applications

Renovation & Existing Conditions Surveys: Document room dimensions, ceiling heights, and diagonal checks in occupied spaces faster than any tape crew. P2P technology lets one person measure across obstructed areas without a second set of hands.

MEP Rough-In Coordination: Verify duct, pipe, and conduit clearances from structural members using indirect measurement functions. Confirm rough-in dimensions before ordering fabricated components.

Flooring, Drywall & Material Estimating: Use Smart Room to calculate square footage and volume instantly. Feed accurate numbers into your estimating software via Bluetooth without re-keying data.

Pre-Construction Field Verification: Confirm column grids, wall offsets, and opening dimensions against architectural drawings before work begins — catching discrepancies before they become RFIs or change orders.

Compatible Accessories

• Leica DISTO Tripod Adapter (DST 360) — enables horizontal 360° P2P measurements
• Leica DISTO Bluetooth Adapter — extend wireless range for large-format layouts
• Leica DISTO Carrying Case — jobsite-ready hard case for transport and storage
• Leica DISTO Plan App — free iOS/Android app for floor plan sketching and data export

Related Guides

• How to Use Point-to-Point Measurement on the Leica DISTO X6
• Leica DISTO X6 vs. X4 — Which Laser Measure Is Right for Your Crew?
• Connecting Your Leica DISTO X6 to the DISTO Plan App
• Best Laser Distance Meters for General Contractors in 2025

Frequently Asked Questions

What is Point-to-Point (P2P) technology on the DISTO X6?

P2P technology uses the X6's dual laser points and built-in tilt sensor to calculate the true distance between any two points in 3D space — without moving the device. This is especially useful for measuring across obstructions, diagonals, or elevated points that a tape measure can't reach efficiently.

Is the Leica DISTO X6 waterproof enough for outdoor jobsite use?

Yes. The X6 carries an IP65 rating, meaning it is fully dust-tight and protected against direct water jets from any direction. It is not rated for submersion, but it handles rain, wash-down, and dusty concrete environments without issue.

Does the DISTO X6 work without the app?

Absolutely. All measurement functions — including P2P, Smart Room, area, volume, and Pythagorean — operate fully on-device with no app or phone required. Bluetooth and the DISTO Plan app add optional workflow benefits for data transfer and floor plan sketching.

What is the warranty on the Leica DISTO X6?

Leica provides a standard 2-year manufacturer warranty on the DISTO X6 against defects in materials and workmanship. As an authorized Leica dealer, Express Tools supports warranty claims and can assist with registration and service coordination.
