Topcon TP-L5B Pipe Laser Package - Red Beam

Overview

The Topcon TP-L5B Red Beam Pipe Laser Package represents the gold standard in underground utility construction. Built for professional contractors who demand precision and reliability, this complete pipe laser system delivers accurate grade control for pipe laying, drainage installation, and utility alignment projects of any scale. The TP-L5B features a highly visible red beam that cuts through ambient light in manholes and pipe sections, dual-axis self-leveling for fast setup, and rugged construction that withstands the harsh conditions of underground work environments.

What sets the TP-L5B apart is its combination of precision and durability. With grade accuracy to 8 arc seconds and a self-leveling range of ±10%, this laser eliminates costly grade errors while dramatically reducing setup time on the job site. The instrument's IP68 rating means it's completely sealed against dust and water submersion, while its robust aluminum housing protects internal components from drops and impacts. Whether you're installing storm drains, sanitary sewers, culverts, or utility conduits, the TP-L5B package includes everything needed to ensure proper grade and alignment from the first pipe to the last.

Express Tools backs this complete package with factory-fresh warranty coverage and expert technical support, ensuring your crew stays productive on every project.

Key Specifications

• Beam Type: Red laser diode, highly visible in pipe applications
• Accuracy: 8 arc seconds (±1/4" at 100 feet)
• Self-Leveling Range: ±10% (±5° in both axes)
• Working Range: Up to 1,000 feet (300m) with optional detector
• Diameter Range: 4" to 48" pipe diameter compatibility
• Grade Range: -10% to +40% adjustable grade settings
• Power Source: Rechargeable NiMH battery pack, 40+ hours runtime
• Environmental Rating: IP68 – dustproof and waterproof to 3 feet
• Operating Temperature: 14°F to 122°F (-10°C to 50°C)
• Display: Illuminated LCD with grade percentage readout
• Weight: 8.8 lbs (4.0 kg) with battery
• Warranty: 2-year manufacturer's warranty

What's in the Kit

• TP-L5B Red Beam Pipe Laser (Main Unit)
• Rechargeable NiMH Battery Pack
• AC Battery Charger with Power Cord
• 12V DC Vehicle Charger for Field Charging
• Standard Pipe Target with Mounting Hardware
• Remote Control for Grade Adjustment
• Rugged Carrying Case with Custom Foam Interior
• Adjustment Tools and Allen Key Set
• Operator's Manual and Quick Start Guide
• Factory Calibration Certificate

Job Applications

• Storm Drain Installation: Maintain precise slope requirements for proper water flow and prevent standing water issues that lead to system failure and costly callbacks.
• Sanitary Sewer Construction: Ensure gravity-fed sewer lines meet engineered grades specified in municipal codes, preventing backflow problems and ensuring long-term system performance.
• Underground Utility Conduits: Establish accurate alignment for electrical, telecommunications, and gas line conduits where proper grade prevents water accumulation and extends infrastructure lifespan.
• Agricultural Drainage Systems: Control elevation and slope in field tile drainage to optimize water removal, improve crop yields, and prevent soil saturation that damages farm productivity.
• Highway Culvert Projects: Align large-diameter culverts over extended distances where precision is critical to prevent roadway washouts and ensure decades of maintenance-free performance.
• Residential Foundation Drainage: Install perimeter drain systems with correct slope to protect home foundations from water damage, eliminating basement flooding and foundation settlement issues.

Compatible Accessories

• TP-L5 Laser Detector – Extends working range beyond visible beam distance for longer runs
• Additional Pipe Targets (4", 6", 8", 12" sizes) – Optimize visibility in various pipe diameters
• Heavy-Duty Tripod with Adapter – Stable positioning for setup stations and alignment checks
• Grade Rod and Target System – Above-ground grade transfer and benchmark verification
• Spare Battery Pack – Eliminate downtime with hot-swap battery replacement
• Protective Pipe Cradle Set – Securely position laser in pipes from 8" to 48" diameter
• Bluetooth Grade Module – Wireless grade data transmission to data collectors
